Specifications of Digital Sensor
Detecting range
0.3-5m
Reaction time
0.1sec / pcs
Sensor quantity
4pcs，Maximum support 8pcs
Accuracy
0.02m
Working temperature
-40ºC to 80ºC
Angle of wave
Single with 60-80ºC or dual with 120ºC， Vertical with 60ºC
Frequency
40KHz
Waterproof
IP67
Split 4PIN cable
1M; Male and female each with 50CM length
Specifications of Wireless main box
| Voltage | 12V-48V DC |
|---|---|
| Working temperature | -40ºC to 80ºC |
| Main box size | 60*37*17mm |
| Input voltage | 9-60V input |
| CPU Walt | <=2W |
| LED Walt | <=3W |
| Frequency | 433MHz |
| Emission Frequency | 20dBm |
| Sensitivity | -113dBm |
| Transmit distance | >80m |
| Power with Surge design | 600W with two way 60V TVS , unti-nuisance |
|
Connector |
4pin aviation |
