AHD camera
  • Name: AHD 1080P 960P 720P rearview camera,12V 24V heavy duty car side front back up camera for bus truck
  • Product Code: ST-7000
  • Incoterm: EXW
  • Availability: Small quantity in stock
Share to:

AHD 1080P 960P 720P rearview camera,12V 24V heavy duty car side front back up camera for bus truck


Specifications:


Type of sensor: Korea CMOS sensor camera1)Ip rating:Ip66-68
2)Images Sensors:1/3" APTINA CMOS//NVP
3)TV System:PAL/NTSC
4)Effective Pixels:512X582/512X492
5)Sensing Area(mm):4.9X3.7
6)Resolution(TV Lines) 800TLV
7)Min.illumination(Lua/F1.2) 0
8)Horizontal Sync.Frequency(KHZ) 1/50 or 1/60~1/10,000
9)Vertical Sync.Frequency(HZ) 15.625/15.734
10)Video Output: 1Vp-p,75 Ohm
11)BLC : Auto
12)S/N ratio : Better than 48dB
13)Lens: F=2.8mm/F=2.0
14)Lens Angle(Deg.) : 170 degree
15)Current Consumption(mA) : 290
16)Power Supply(DCV): 12V
17)Operating Temperature(Deg.C): -20~+70(RH95%Max.)
18)Storage Temperature(Deg.C) : -40~+80(RH95%Max.)


Our services:

1. All products have been strictly checked in house before packing
2. All products have been well packed before shipping
3. One year warranty is provided for all models
4. We will provide replacement free of charge during warranty
